12
2. PRODUCT SPECIFICATIONS
RB31FE***
RB31FE***
RB30FE***
RB31FD***
RB31FW***
RB31F****
RB32F****
RB29F****
RB29F****
RB28F****
RB29FD***
RB29FW***
RB29F****
RB28F****
Compon nents for Freezer
Refrigerant R-600a
Freezing Capacity
4-Star
Compressor
Model
MSV488AL1P/
TT1
MSV488AL1R/
TT1
MSV488AL1R/
TT1
MSV488AL1R/
TT1
MSV488A-L1P
MSV488AL1R/
TT1
MSV488AL1R/
TT1
MSV488AL1R/
TT1
Starting type BLDC BLDC BLDC BLDC BLDC BLDC BLDC BLDC
Oil Charge 200 ± 10cc 200 ± 10cc 200 ± 10cc 200 ± 10cc 200 ± 10cc 200 ± 10cc 200 ± 10cc 200 ± 10cc
Evaporator Freezer Split Fin Type
Condenser
(Convection Type)
Forced Type Convection Type Forced Type Convection Type
Dryer Molecular Sieve XH-9
Capillary Tube Cu, Φ1.8XID0.75XL4000 Cu, Φ1.8XID0.75XL3500 Cu, Φ1.8XID0.75XL4000 Cu, Φ1.8XID0.75XL3500
Electric Components
Defrost Heater
Conducting
at F Defros
230V / 150W
Thermal-Fuse for preventing
overheating of Refrigerator
Defrost-Heater
AC250V, 10A, 109~110℃
Over-load
Relay
Model
4TM308RFBYY-82
Temp. ON 130℃ ± 5
Temp. OFF 61℃ ± 9
Rated Voltage 200 - 240V ~ 50Hz, 220V ~ 60Hz
Motor
F ROOM 12035QE12MY or DREP8020RA (DC 12V)
C ROOM
G1538S12D1-SS-
TTL(DC 12V)
- - -
G1538S12D1-SS-
TTL(DC 12V)
- - -
Damper
R ROOM
Damper
NSBA001TF1, DC12V, 60mA
Cool Select
Zone
NSBY001TE1, DC12V - - NSBY001TE1, DC12V - -
Lamp LED Type DC 12V, 65*10*1.6T, FR4, 3PKG
Door Switch Reed switch, DC 200V, 1.5A
