Samsung RB37A50N0WW [8/101] Product specifications
![Samsung RB37A50N0WW [8/101] Product specifications](/views2/1993868/page8/bg8.png)
8
2. PRODUCT SPECIFICATIONS
2-2) Model Specification
Item SPECIFICATION
Models
RB37A**9** RB37A**5** RB37A**0** RB37A**1**(CIS)
Net
Capacity
Total
365 367 367 367
Refrigerator
267 269 269 269
Freezer
98 98 98 98
Net
dimension
W (mm)
595 595 595 595
D (mm)
647 647 647 647
H (mm)
2010 2010 2010 2010
Rated Voltage and Frequency 230V / 50HZ
Motor Rated
Consumption
Power
c-fan 12v,3w - - -
r-fan 12v, 2.2w - - -
f-fan 12v, 2.2w 12v, 2.2w 12v, 2.2w 12v, 2.2w
Electric Heater Rated
Consumption Power
230V, 150W
Kind of Refrigerator INDIRECT COOLING METHOD REFRIGERATOR
Refrigerant/
Refrigerant Amount
73Gr 63Gr 63Gr 63Gr
Freezer Performance 4-STAR
Product Weight 81.5kg 73.5kg 73.5kg 74.5kg
