Electrical Installation Procedure

When installing the machine, always observe the local regulations and standards. The appliance is supplied

with a moulded power cord. A suitable mains power supply socket should be available within easy access of

the appliance so that it can be disconnected easily after install.

Plumbing Installation Procedure

Ensure that the equipment is installed according to local plumbing & water regulations.

Mains water pressure required (limits): 14.5 -145psi (100 -1000kPa, 0.1 - 1MPa).

Fit a stop valve on a cold water line and attach a 3/4” BSP male tting,

(E.g. 3/4” x 1/2” 311 or washing machine type stop valve).

The SP9 Head has a drip tray attached with a drain outlet which should be plumbed to waste.

Maintenance

This machine has been designed to give many years of trouble free service. The only regular maintenance

required is occasional de-scaling.

Descaling Procedure

• Isolate machine from power supply.

• Isolate machine from water supply.

• ALLOW TO COOL COMPLETELY!

• Drain water from machine.

• Remove all lids.

• Remove as much scale as possible by hand, paying particular attention to level probes (White plastic

with steel tab). Be very careful not to damage any attachments.

• Use ScaleKleen, Marco part No. 8000270 or similar. Follow instructions carefully.

• Thoroughly clean and ush the machine before re-use.

• Follow installation and rst time operation instructions.

• Run the brew cycle a minimum of two times using only water to fully ush the de-scale solution through

the SP9 Head.

Operating the SP9 Head for the rst time

The SP9 Head is connected to the SP9 Boiler by silicone hoses and a ying lead. The SP9 Head’s silicone

hoses should be connected to the SP9 Boiler’s hose adapters and secured with the supplied hose clips. The

connections on both machines are marked “A” & “B”, connect “A” to “A” and “B” to “B”.

The SP9 Boiler vent should be connected to a hose adaptor marked vent on a SP9 Head.

The SP9 Boiler ideally should be positioned directly below the SP9 Head installed position.

Please refer to installation diagrams on pages 10 and 11 of this booklet.

Once the SP9 Head installation procedure has been carried out calibrate the SP9 Head. The calibration

should only be conducted by a trained service engineer, see guideline on the following page.
