Luxstahl MARCO SP9 Head [9/16] Cutting template

9

CUTTING TEMPLATE

NOT TO SCALE

The above drawing illustrates where to position the counter cut outs if two SP9 Heads are being installed.

For a 1:1 scale cutting template please see the back page of this manual.

Option 1:

Using an 80mm hole saw, drill two holes as per the drawing.

Option 2:

Use a jig saw or similar cutting device to cut out the full obround shape.
