Operating the SP9 Boiler for the rst time

• Check that all installation procedures have been carried out.

• Ensure the water valve is on.

• Plug in the SP9 Boiler to an appropriate electrical supply and press the power button on the front of the

machine.

• The light will glow green and the machine will ll to a safe level, above the elements, before heating.

• The “Ready/Status” light will cycle two red ashes while the machine is lling to the safe level.

• After this amount of water has heated to the set point the machine will draw more water in until the

temperature drops by 1 or 2 degrees. The machine will then heat again. This heat ll cycle continues until

the SP9 Boiler is full.

• Whilst the machine is above the safe level and lling, the “Ready/Status” light will remain blank.

• The “Ready/Status” light will glow green when the machine is both full and up to normal operating

temperature.

• Ensure the SP9 Boiler is set to SP9 mode for use with the SP9 Head.

• The SP9 Boiler takes 15 minutes to heat up initially.

• The SP9 Boiler is now ready for use.

NOTE: Because the machine is electronically controlled no priming is necessary.

Dispense Volume Calibration

1. Once all installation procedures are carried out the SP9 Head is ready to be calibrated.

2. Turn the quantity dial to maximum value.

3. Turn time dial to between 2-3 minutes.

4. Place a large container (>1 litre) of known weight under the spray head.

5. Initiate brew by toggling switch.

6. Weigh & record brew output.

7. The output should be 750g + or - 10g.

8. If output is within +/- 10g of 750g further calibration is not necessary.

9. If not, to enter calibration mode, hold down the toggle switch for a minimum of 3 sec.

10. A long beep will emit to conrm that the machine is in calibration mode.

11. Enter the mass recorded via the brew switch using the following example:

o If 724g was measured.

o The toggle switch is used to input each digit successively.

o To enter ‘7’ the toggle switch is toggled 7 times

o A long beep will emit.

o To enter the ‘2’ toggle the toggle switch 2 times.

o A long beep will emit.

o To enter the ‘4’ toggle the toggle switch 4 times.

o To enter a ‘0’ value simply do not toggle the toggle switch.

o If calibration is successful a long beep will emit at the end of the

process, if not multiple short beeps will emit.

12. Verify calibration by repeating steps 2 – 5.
