11
Basic Operations
On the display
1
Text/graphic information display (page 13)
The following information is displayed
according to the display mode.
•Elapsed time mode
•Title mode
•Graphic mode
Track number Elapsed time
Play status
During playback: or is
displayed alternately.
In stop mode: is displayed.
While locating tracks: > or .
is displayed.
While searching a point in a track:
M or m is displayed.
Song title Artist name
Play status
2 Play mode indication (page 13)
The selected play mode is displayed.
3 AVLS indication (page 12)
The indication lights up while the AVLS
function is activated.
4 MEGA BASS indication (page 12)
The indication lights up while the MEGA
BASS function is activated.
5 Battery remain indication (page 7)
The remaining battery power is
displayed.
4
32
1
5
Spectrum analyzer
Bit rate (page 19)
: songs recorded at 132kbps
: songs recorded at 105kbps
: songs recorded at 66kbps
: songs recorded at 47kbps*
* If you convert a monaural audio
MP3/WAV file, the bit rate will be
47kbps.
