Falmec Zeus 90 PRO [12/80] Electrical connections

12

extracted is well ventilated, in compliance with the current regulations.

Mounting instruction: see section “O” of the booklet.

ELECTRICAL CONNECTIONS

D

(Section reserved for qualified installers)

WARNING! Before doing any work inside the range hood, disconnect the appliance from the mains power supply.

Check that the wires inside the range hood are not disconnected or cut; if this is the case, contact your nearest service centre. The

electrical connections must be performed by qualified personnel.

- fit a plug that is suitable for the load to the power cable, and connect it to a suitable power outlet.

For appliances that come supplied with cable and plug please ensure they are plugged into a circuit suitable for this appliance.

Please refer to a qualifed person. (See technical specifications in point B).

The manufacturer declines all liability if the safety standards are not observed.

E

RANGE HOOD WITH OUTSIDE DISCHARGE (exhaust)

In this version, the fumes and steam from the kitchen are conveyed outside through an exhaust duct.

The exhaust conveyor that protrudes from the upper part of the range hood must be connected to a duct that carries the fumes and steam

outside. In this version, the charcoal filters, if fitted, should be removed; to do this, see the instructions in point F. There must be adequate

ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels, according to the standard.

Check that the charcoal filters are fitted to the motor, and if not, install them as described in the instructions in point H.

If the hood is of filtering type, remove the non-return valve fitted at the motor’s outlet.

For maximum efficiency, the third speed should be used when there are strong odours or a lot of steam, the second speed in normal

when starting to cook, and left on until the odours disappear.

G

OPERATION

Pressed: the light is on

Light pushbutton

• ON: light on (the pushbutton is lit);

• OFF: light off;

Pushbutton -

Press to reduce motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the timer LEDs).

Pushbutton +

Press to increase motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the timer LEDs).
