![Franke A800 [22/64] Refrigeration unit ke200](/views2/1996983/page22/bg16.png)
Installation and technical data
Page 20
FoamMaster SU12 (Twin) (optional)
Weight Approx. 26kg
Width/Depth/Height 340mm/475mm/540mm
Device type FCS4048
Milk container 5 l
Electrical connection EU 220 – 240 V1L N PE50/60 Hz
SU05 FM1.95 – 2.3kW
SU05 MSCurrent consumption: 0.72 A
USA 120 V1L N PE60Hz
SU05 FM1.44kW
SU05 MSCurrent consumption: 1.5 A
Electric cable 1800mm
Ambient conditions Humidity: max. 80%
Ambient temperature: 10 – 32 °C
Coolant R134a /40 g
Climate class N (temperate climate)
Noise emission < 70 dB (A)
Cooling temperature 2.0 - 5.0 °C
Empty weight SU05 MS 16.1kg (with base 17.6 kg)
SU05 FM 23.0kg (with base 24.5 kg)
Width/Depth/Height 270mm/474 mm/540 mm
Under-counter refrigeration unit UT12 (Twin) (optional)
Chill & Cup (optional)
Payment system AC (option)
Base refrigeration unit UC05 (optional)
Refrigeration unit KE200 (optional)
Flavor Station FS30 (option)
Weight Approx. 26kg
Width/Depth/Height 320mm/467mm/547mm
Weight Approx. 29kg
Width/Depth/Height 320 mm/471 mm/502mm
Device type FCS4056
Electrical connection 85–264V1L N PE
Weight Approx. 18 kg
Wastewater tank/Drip tray 3l
Width/Depth/Height 200mm/451mm/542mm
Weight Approx. 27kg
Width/Depth/Height 320 mm/646 mm/238 mm
Weight Approx.13kg
Width/Depth/Height 225mm/453mm/330mm
Device type FCS4055
Capacity Up to 3 varieties of syrup
Electrical connection 220–240 V1L N PE75 W50/60 Hz
Fuse: 10A
Electric cable 1800mm
Weight Approx. 17kg
Width/Depth/Height 200mm/451mm/545mm
SU05 MS (optional)
Device type FCS4054
Capacity Up to 120 cups (depending on cup size)
Electrical connection 220-240V1L N PE120 W50/60Hz
Fuse: 10A
Weight Approx. 20kg
Width/Depth/Height 270 mm/475mm/540mm
Cup warmer CW (optional)
