51
DEFRNLITESPTNOSVDAELRU EN
0478 131 9922 D - EN
VIKING GmbH
Head of Design
Transporting STIHL batteries:
STIHL batteries meet the requirements
specified in UN manual
ST/SG/AC.10/11/Rev. 5 Part III,
subsection 38.3.
The user may transport STIHL batteries by
road to the place of use of the machine
without further restrictions.
Country-specific legislation must be
observed in the case of air or sea
transport.
For further transport instructions, see
www.stihl.com/safety-data-sheets
REACH:
REACH is an EC Directive for the
registration, evaluation, authorisation and
restriction of chemicals. For information on
compliance with the REACH Directive
(EC) No. 1907/2006, see
www.stihl.com/reach
19. Technical specifications
Battery
Type Lithium-ion
The machine can be operated with STIHL
batteries of the type AP.
Information on the run time of the machine
and the charging time can be found in the
battery supplementary sheet and the
instruction manual for the charger.
Chargers AL 100, AL 101, AL 300,
AL 500
See instruction manual for the charger.
MA 443.1, MA 443.1 C
Serial number 6338
Motor manufacturer Domel
Type EC motor
Voltage 36 V~
Power input 900 W
Protection class III
Type of protection IPX 1
Cutting utilities Cutter bar
Cutting width 41 cm
Speed of cutting
utilities 3000 rpm
Cutter bar drive Permanent
Tightening torque for
blade fastening
screw 10 - 15 Nm
Cutting height 25 - 75 mm
Grass catcher box 55 l
Wheel diameter
(front) 180 mm
Wheel diameter
(rear) 200 mm
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
94 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
80 dB(A)
Uncertainty K
pA
2dB(A)
MA 443.1
Length 138 cm
Width 49 cm
Height 107 cm
Weight (without
battery) 18 kg
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
1,70 m/sec
2
Uncertainty K
hw
0,85 m/sec
2
Measurement in accordance with
EN 20643
MA 443.1 C
Length 138 cm
Width 49 cm
MA 443.1, MA 443.1 C
Height 108 cm
Weight (without
battery) 20 kg
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
1,30 m/sec
2
Uncertainty K
hw
0,65 m/sec
2
Measurement in accordance with
EN 20643
20. Troubleshooting
# If necessary, contact a specialist
dealer; VIKING recommends VIKING
specialist dealers.
MA 443.1 C
