17
For appliances that come supplied with cable and plug please ensure they are plugged into a
circuit suitable for this appliance.
Please refer to a qualifed person. (See technical specifications in point B).
The manufacturer declines all liability if the safety standards are not observed.
E
INTERIOR RECIRCULATING HOOD VERSION
The sky hood is only available in the interior recirculating version with carbon filters. For
replacement, please see sect. G1.
F
ELECTRONIC PUSH BUTTON
CONTROL PANEL OPERATION
1: Timer
Flashing RED light indicates that the timer function is active. This function
can only be enabled if the motor is already active at any speed when the corresponding
key is pressed (long press or not). This function activates the auto power off function of the
hood after 15 minutes.
With the Timer function active, the hood can be turned off by the user and the function will
be disabled. The Timer function remains associated to a speed. Changing the speed with the
timer function active involves the deactivation of the latter.
2: 1st Speed
If the LED is off, the key a non-prolonged pressure of the key activates the hood at the 1st
speed as well as the related LED. The function is activated by releasing the key.
By pressing the key, if the LED is off and another speed is active, you can select the 1st
speed, turn the related LED on, and turn the LED associated to the previously selected
speed off.
When the LED is on and the key is pressed, both the LED and MOTOR will turn off.
When the LED is off, if the key is pressed for at least 3 seconds, the recirculation function
activates. During the recirculation function (which lasts 24 hours), the LED flashes .
From the activation of this function, the hood will remain active for 1 hour at the 1st speed,
then it will stop for 3 hours and reactivate for one more hour. These cycles are repeated
until timeout.
With this feature enabled, you cannot select other speeds. To Disable this function, hold key
2 for at least 3 seconds.
3: 2nd Speed
By pressing the key (long press or not), if the LED is off and another speed is active, you can
select the 2nd speed, turn the related LED on, and turn the LED associated to the previously
selected speed off.
If the LED is off and no speed is active, pressing the key has no effect.
When the LED is on, pressing key 3 has no effect.
To turn off the hood, first select the 1st speed, then press that key again.
4: 3rd Speed
By pressing the key (long press or not), if the LED is off and another speed is active, you can
select the 3rd speed, turn the related LED on, and turn the LED associated to the previously
selected speed off.
If the LED is off and no speed is active, pressing the key has no effect.
When the LED is on, pressing key 4 has no effect.
To turn off the hood, first select the 1st speed, then press that key again.
5: 4th Speed
By pressing the key (long press or not), if the LED is off and another speed is active, you can
English
