BERTAZZONI KU90 PRO 1 X A [14/31] Filter removing

In this version, the air passes through charcoal lters for purication, and is then recirculated back

into the kitchen.

Check that the charcoal lters are tted to the motor, and if not, install them as described in the

previuous image.

If the hood is of ltering type, remove the non-return valve tted at the motor’s outlet.

For maximum efciency, the third speed should be used when there are strong odours or a lot of

steam, the second speed in normal conditions, and the rst speed for keeping the air clean with

minimum energy consumption. The range hood should be switched on when starting to cook, and

left on until the odours disappear.

ELECTRONIC CONTROL PANEL (Fig. 7)

Light pushbutton (1)

- ON: light on (the pushbutton is lit);

- OFF: light off;

Pushbutton - (3)

Press to reduce motor speed.

Pushbutton + (3)

Press to increase motor speed.

(In the speed 4 the pushbutton presents an intermittant light. The speed 4 or intensive is timed and

after 7 minutes the motor automatically switches to speed 3).

Pushbutton On / Off (2)

Function: it turns hood on and off.

When you switch On the hood the motor starts at rst speed.

Pushbutton Timer (4)

This function allows the automatic turning off the hood after 15 minutes for the speeds 1, 2, 3 (the

pushbutton is lit).

METAL FILTERS

Open the panel (Fig. 4). Use handle to remove the metal grease lter.

CHARCOAL FILTERS

To replace the charcoal lters, proceed as follows: remove the metal lters as described above.

The two lters located at the ends of the motor can now be easily accessed.

To install the new  lters see picture.

The hood is equipped with high efciency, low power consumption LED lighting (light on the work

top and decorative light on the glass panes), with high durability under normal use conditions.

On the product there are two leds from 1,1 watts.

OPERATIONS

FILTER REMOVING

LIGHTING

INSTALLATION IN RECIRCULATING MODE
