Aqua Mini Full DC Inverter Unitary Chiller 50Hz
19
8. Electric Characteristics
Model
Outdoor Unit Power Supply Compressor OFM
Hz Voltage Phase Min. Max. MCA TOCA MFA MSC RLA kW FLA
MGRH5A-PA1Z
50Hz 220~240V 1Ph 198V 264V 10.1 14.6 20 29.5 8.1 0.195 1.65
MGRH7A-PA1Z
50Hz 220~240V 1Ph 198V 264V 10.1 15.6 20 29.5 8.1 0.195 1.65
MGRH10A-PA1Z
50Hz 220~240V 1Ph 198V 264V 15.1 25.0 30 52 12.1 0.20 1.8
MGRH12A-PA3Z
50Hz 380~415V 3Ph 342V 456V 8.6 8.9 15 44 6.9 0.20 1.8
MGRH14A-PA3Z
50Hz 380~415V 3Ph 342V 456V 8.6 9.6 15 44 6.9 0.20 1.8
MGRH16A-PA3Z
50Hz 380~415V 3Ph 342V 456V 8.6 10.1 15 44 6.9 0.20 1.8
Remark:
MCA: Min. Current Amps. (A)
TOCA: Total Over-current Amps. (A)
MFA: Max. Fuse Amps. (A)
MSC: Max. Starting Amps. (A)
RLA: Rated Current Amps. (A)
OFM: Outdoor Fan Motor
FLA: Full Load Amps. (A)
kW: Rated Motor Output (kW)
