Aqua Mini Full DC Inverter Unitary Chiller 50Hz
37
25.1
25.2
25.3
25.4
25.5
25.6
25.7
25.9
25.8
25.10
25.11
No. Part Name Quantity No. Part Name Quantity
1
Right-front plate ass'y
1 22
Differential pressure switch
1
2
Four-way valve parts
1 23
Hydraulic meter
1
2.1
Four-way valve ass'y
1 24
Display box ass'y
1
2.2
Pressure switch
1 25
Outdoor electrical control box ass'y
1
3
Welded parts of base
1 25.1
Inverter module
1
4
Suction pipe ass'y
1 25.2
Radiator
1
4.1
Pressure controller
1 25.3
Three phase bridge
1
5
Accumulator ass'y
1 25.4
Aluminum electrolytic capacitors
2
6
Fixed plate ass'y of compressor
1 25.5
outdoor unit power supply board
1
7
Compressor
1 25.6
Resistance
2
8
EXV ass'y
1 25.7
AC contactor
1
8.1
Electronic expansion valve
1 25.8
Wire joints,14P
1
8.2
Expansion valve wire(CAM-MD12GRSZ-5)
1 25.9
Outdoor main control board ass'y
1
9
Exhaust valve ass'y
1 25.10
Wire joint, 2p
1
9.1
Exhaust valve
1 25.11
Terminal block, 3P
1
10
Connection pipe ass'y
1 26
Right back plate
1
11
Base
1 27
Inductance parts ass'y
1
12
Fixed plate of inlet/outlet pipe
1 27.1
Reactance
1
13
Connection pipe parts of water pump
1 28
Condenser ass'y
1
13.1
Water charge valve
1 29
Coaming ass'y
1
13.2
Safety valve
1 30
Bracket ass'y, net
1
14
Drain pipe adapter
2 31
Installation plate of expansion tank
1
15
Water pump
1 32
Top cover ass'y
1
16
Coaming I
1 33
Expansion vessel
1
17
Plate heat exchanger ass'y
1 34
Rear-left supporting board
1
17.1
Plate heat exchanger
1 35
Motor bracket assembly
1
17.2
Electrical heater of plate heat exchanger
1 36
DC Motor
2
18
Rubber gasket
1 37
Axial fan
2
19
Coaming II
1 38
Front Panel
1
20
Connection pipe ass'y of differential pressure valve
1 39
Net
2
20.1
Electrical heater of differential pressure valve
1 40
Handle
3
21
Gas-liquid separator
1
