Aqua Mini Full DC Inverter Unitary Chiller 50Hz
63
2) Setting water temperature:
Method 1:Press the “▲” or “▼” to adjust the water temperature after the controller is powered on. Press
“OK” key or wait for 7 seconds to confirm.
Method 2:Setting water temperature in parameters function. Press “FUNCTIONS” key under main
interface once to enter water temperature setting interface. Press the “▲” or “▼” to adjust the water
temperature .Press “OK” key or wait for 7 seconds to confirm.
Press
once
RUN
WATER
TEMP.
TIMER
(Press for 3sec to
cancel timer)
(Press for 3sec to
unlock)
MODE
FUNCTIONS
ON
Wa
ter temperature setting check: To check the water temperature setting value, press the “
” or “
▲
”key
under the main page(the page displayed after the controller is powered on).
c. Setting function parameters
Press “FUNCTIONS” key to choose operation parameters. The setting function parameters will change
as the following order each time the key is pressed:
→
→
W
a
t
e
r
t
e
m
p
e
r
a
t
u
r
e
T
im
in
g
C
lo
c
k
U
n
i
t
N
O
.
→
W
a
t
e
r
p
u
m
p
f
o
r
c
e
d
→
1) Timing se
tting: 3 timing periods can be set on the wired controller: Timer 1, Timer 2, Timer 3. These 3
timers can control the main unit to be turned ON and OFF 3 times at most during a day.
2) Setting method: press “FUNCTIONS” key under main page twice to enter timing setting. Then the LCD
will display as the following:
1
TIMER
ON
