DM2000 Version 2—Owner’s Manual
55 Основы управления микшером
Использование клавиатуры
Клавиатура,совместимаясPS/2,можетбытьподключенакпортуKEYBOARDи
использованадлявводазаголовковприпоявленииокнаTitleEdit.Помните,что
поддерживаютсятолькоклавиатурысраскладкойСШАна101и104кнопки.
Можновводитьсимволы,включаябуквы,цифрыизнакипунктуации,поддер-
живаемыеDM2000.СимволапоявляютсянепосредственновокнеTitleEdit,
также,какипривводесDM2000.Следующаятаблицапоказывает,какдоугие
кнопкисоотносятсясфункциямиокнаTitleEdit.
Кнопка Функция окна Title Edit Описание
ESC CANCEL Отменяет ввод заголовка
RETURN/ENTER OK Вводит заданный заголовок
CAPS LOCK SHIFT LOCK Меняет верхний и нижний регистр
SHIFT — Переключает на верхний регистр
Backspace — Стирает символ влево
Cursor (left/right) Кнопки левая/правая
стрелка
Передвигает курсор внутри заголовка
INSERT INS Меняет режимы вставки и замены символов
DELETE DEL Стирает выбранный символ
SPACE bar SPACE Вставляет пробел на текущей позиции курсора
Дисплеи полосы каналов
Флюоресцирующиедисплеиполосыканаловотображаютинформациювсоответ-
ствиисполосамиканаловкакописанониже.
Выможетенастроитьихяркость,используянастройкуChannelStripDisplay
Brightness,какпоказанонастр.277.
Выбранный канал
Границадисплеяполосыканаловвыбранногоканалазагорается,какпоказано
здесь.
Датчик фейдера (Fader Touch Sense)
ПрикасаниикнопокфейдеразагораетсясоответствующийиндикаторTouch
Sense,какпоказанонарисунке.
Индикаторы маршрутизации
Этииндикаторыпоказывают,вкакойканалвыходамаршрутизированканал
входа:с1по8–выходныхшинBusOut,“S”–выходStereoOut,“D”–выходDirect
Out.
Индикаторы EQ, Insert, Delay, Comp и Gate
Этииндикаторыпоказывают,включеныиливыключеныфункцииEQ,Insert,Delay,
CompиGateканалов.
Using a Keyboard 55
DM2000 Version 2—Owner’s Manual
Using a Keyboard
A PS/2 compatible keyboard can be connected to the KEYBOARD port and used
for quick title entry while the Title Edit window is displayed. Note that only 101
and 104-key U.S. keyboards are supported.
Characters, including letters, numbers, and punctuation marks, supported by the
DM2000 can be entered. Characters appear directly in the Title Edit window, the
same as when they are entered on the DM2000. The following table shows how
other keys correspond to Title Edit window functions.
Channel Strip Displays
The fluorescent channel strip displays show information regarding the
channel strips, as described below.
You can adjust their brightness by using the Channel Strip Display
Brightness preference on page 277.
Selected Channel
The border of the currently selected channel’s channel strip display lights
up like this.
Fader Touch Sense
When fader knobs are touched, the corresponding Touch Sense indica-
tors light up like this.
Routing Indicators
These indicators show to which Output Channels an Input Channel is
being routed: 1 through 8 being the Bus Outs, “S” being the Stereo Out,
and “D,” the Direct Out.
EQ, Insert, Delay, Comp & Gate Indicators
These indicators show whether a channel’s EQ, Insert, Delay, Comp, and
Gate functions are on or off.
Key Title Edit Window function Description
ESC CANCEL Cancels title entry
RETURN/ENTER OK Enters the specified title
CAPS LOCK SHIFT LOCK Toggles between uppercase and lowercase
SHIFT — Switches to uppercase characters
Backspace — Deletes the character to the left
Cursor (left/right) Left/right arrow buttons Moves the cursor within the title
INSERT INS Toggles between insert and overwrite modes
DELETE DEL Deletes the selected character
SPACE bar SPACE Inserts a space at the current position
