Roland TM-2 Trigger Module [19/23] Main specifications
![Roland TM-2 Trigger Module [19/23] Main specifications](/views2/2007943/page19/bg13.png)
19
ENG
JPN
DEU
FRA
ITA
ESL
POR
NLD
Main Specications
Roland TM-2: Trigger Module
Connectors
OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
PHONES jack: Stereo miniature phone type
TRIG IN jack x 2: 1/4-inch TRS phone type
MIDI (IN, OUT) connectors
DC IN jack
Interface SD/SDHC memory card (Max. 32 GB)
Power Supply
AC adaptor,
Rechargeable Ni-MH battery (HR6) or Alkaline battery (AA, LR6) x 4
Current Draw 400 mA
Expected battery life
under continuous use
Rechargeable Ni-MH battery: Approx. 6 hours (When using batteries having a capacity of 2,000 mAh)
Alkaline battery: Approx. 4.5 hours
* The time may vary according to usage conditions, batteries used, and type of SD memory card used.
Dimensions 135 (W) x 130 (D) x 59 (H) mm 5-3/8 (W) x 5-1/8 (D) x 2-3/8 (H) inches
Weight
(excluding batteries
and AC adaptor)
360 g 13 oz
Accessories Owner’s manual, Leaet “USING THE UNIT SAFELY”, AC adaptor, Mounting plate, Screw x 2
Options
(sold separately)
Acoustic drum triggers: RT series Kicks: KD series
Pads: PD series, PDX series, BT-1 Cymbals: CY series
* In the interest of product improvement, the specications and/or appearance of this unit are subject to change without prior
notice.
Copyrights
• The copyright of content in this product (the sound waveform data,
style data, accompaniment patterns, phrase data, audio loops and
image data) is reserved by Roland Corporation.
• Purchasers of this product are permitted to utilize said content
(except song data such as Demo Songs) for the creating, performing,
recording and distributing original musical works.
• Purchasers of this product are NOT permitted to extract said content
in original or modied form, for the purpose of distributing recorded
medium of said content or making them available on a computer
network.
Licences/Trademarks
• MMP (Moore Microprocessor Portfolio) refers to a patent portfolio
concerned with microprocessor architecture, which was developed
by Technology Properties Limited (TPL). Roland has licensed this
technology from the TPL Group.
• The SD logo (
) and SDHC logo ( ) are trademarks of SD-3C,
LLC.
• This product contains eCROS integrated software platform of eSOL
Co.,Ltd. eCROS is a trademark of eSOL Co., Ltd. in Japan.
• Roland and V-Drums are either registered trademarks or trademarks
of Roland Corporation in the United States and/or other countries.
• Company names and product names appearing in this document
are registered trademarks or trademarks of their respective owners.
