6.3.5 Power plug and wiring

• The LA8 amplified controller is supplied with a CEE 7/7 power plug (16 A/250 V grounded).

• The LA8US amplified controller is supplied with a NEMA L5-30P power plug (30 A/125 V grounded).

• The LA8JP amplified controller is supplied with the power plug selected by the Japanese distributor.

If the power plug is not appropriate it can be cut off. Then, the power cable must be wired to a suitable plug in the

following manner:

Table 3: Power cord wiring color code

Country

Live

Neutral

Earth

Europe Brown Blue Green / Yellow

USA Black White Green

Japan Black White Green

Plug replacement must be done by qualified personnel only.

The specific safety regulations of the country of use must be strictly applied.

The plug must be approved for the specific voltage and current rating given in Table 2.

The ground connection of the supplied AC power cord is a safety feature. Do not attempt to disable it by

using an adaptor or by other methods.

A new fixed power panel with larger gauge wiring is quite often required to connect the LA8US so as to

meet the 30 A specification.

Note: Warranty will not cover damages caused by a wiring error.
