7.9 OPTIONS
By selecting the OPTIONS menu and rotating the encoder wheel the user can have access to the 12 different pages
shown in Figure 29 and fully detailed in the next sections. Two of them hold AES/EBU functionalities only (FALLBACK
MODE and AES/EBU IN GAIN) which are not shown in case no LA-AES3 card is fitted/detected in the amplified
controller.
Figure 29: OPTIONS menu pages
NETWORK ADDRESS
192 . 168 . 1 . 110
INPUT MODE
ANALOG
DELAY UNIT
ms
OUT CH TEMP (%)
52% 53% 50% 48%
SPK HANDLING (%)
12% 10% 13% 11%
EN CONTRAST
100%
MAC ADDRESS
00:1B:92:01:02:1B
FIRMWARE VERSION
V1.4.1.23
PRESET VERSION
V2.2
DISPLAY VERSION
V1.4.1.24
OK
ESC
NETWORK ADDRESS
192 . 168 . 1 <123>
OK
ESC
NETWORK ADDRESS
192 . 168 . 1 . 123
OK
ESC
DELAY UNIT
> METERS <
OK
ESC
DELAY UNIT
METERS
OK
ESC
SCREEN CONTRAST
> 30% <
OK
ESC
SCREEN CONTRAST
30%
AES/EBU IN GAIN
+0.0dB
FALLBACK MODE
OFF
