L-ACOUSTICS LA8 [32/56] La la la la888
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

L-ACOUSTICS LA8 [32/56] La la la la888

L-ACOUSTICS LA8 [32/56] La la la la888
LA
LALA
LA8
88
8
AMPLIFIED CONTROLLER
AMPLIFIED CONTROLLERAMPLIFIED CONTROLLER
AMPLIFIED CONTROLLER
USER MANUAL
USER MANUALUSER MANUAL
USER MANUAL
VERSION 4.0
LA8_UM_EN_4-0
w w w . l - a c o u s t i c s . c o m
30
3030
30
7.3.2 Main menu
The main menu gives access to 6 pages that are briefly described in the following table. Please refer to the appropriate
section for detailed instructions.
Note: All parameters in each amplified controller are also available through the L-NET network using LA NETWORK
MANAGER Software (refer to the LA NETWORK MANAGER User manual [3.4]).
Table 5: Main menu description
Menu pages
Functionalities Section
LOAD PRESET
Load and initiate a preset (memories 1 to 99). [7.4]
STORE PRESET
Save user preset and parameters (memories 1 to 10). [7.5]
DELETE PRESET
Delete a preset (memories 1 to 10). [7.6]
PRESET PARAMETERS
Control and set mute, gain, delay, and polarity (when available).
[7.7]
CLEAR GRP PARAM
Remove
group parameters
defined in LA NETWORK MANAGER
Software (name, gain, delay, and contour EQ).
[7.8]
OPTIONS
Select the LA8
IP address
,
input mode
(ANALOG or AES/EBU),
delay unit, and LCD screen contrast.
Provide real-time relative temperature and RMS output voltage for
each amp channel.
Show MAC address as well as FIRMWARE, PRESET LIBRARY, and
DISPLAY versions.
[7.9]
The following procedure and Figure 22 explain how to access one of these menus:
1. Press and release the encoder wheel.
2. Rotate the encoder wheel clockwise or counterclockwise until the desired menu is selected.
3. Press the OK key or the encoder wheel to enter menu or press the ESC key to return to the main screen.
Figure 22: Menu selection procedure
To simplify the navigation through the menu control screens, the
LCD displays 2 types of arrow cursors: the position cursor (top left)
and the selection cursor (top right).
Position cursors
Indicates the start of a menu and prompts the user to turn the
encoder wheel clockwise to scroll down menu’s other
functionalities.
Prompts the user to turn the encoder wheel clockwise or
counterclockwise to scroll up and down menu’s other
functionalities.
Indicates the end of a menu and prompts the user to turn the
encoder wheel counterclockwise to scroll up menu’s other
functionalities.
Selection cursors
Indicates another menu level or function, accessible by pressing
the OK key or the encoder wheel. Press the ESC key to return
to the last menu.
Indicates that no additional menu level or function is accessible.
Turn the encoder wheel to access another menu or press the
ESC key to return to the last menu.
LOAD PRESET
STORE PRESET
STORE PRESET
DELETE PRESET
DELETE PRESET
PRESET PARAMETERS
PRESET PARAMETERS
CLEAR GRP PARAM
CLEAR GRP PARAM
OPTIONS
0.0 0.0 0.0 0.0
OPTIONS
