LA8_UM_EN_4-0
w w w . l - a c o u s t i c s . c o m
31
3131
31
7.4 LOAD PRESET
This LOAD PRESET menu is for loading a preset from the 99 onboard memory locations:
11 to 99: Allocated memory locations for L-ACOUSTICS
®
factory presets.
1 to 10: Allocated memory locations for user presets (initialized from a factory preset).
To load a preset, select the LOAD PRESET menu and apply the following procedure (see also Figure 23):
1. Turn the encoder wheel to display the desired preset.
2. Press the OK key or the encoder wheel to select the preset (or press the ESC key to cancel and return to
the last menu). The ARE YOU SURE? message will be displayed.
3. Press the OK key or the encoder wheel to load the preset (or press the ESC key to cancel and return to the
last menu).
When the preset is loaded and activated, the LCD screen will go back to the Main screen.
Figure 23: Loading a preset
Note: The upper line of the LCD displays the preset family while the bottom line displays the preset name.
* If the controller has been assigned to a group [7.8] the sequence is continued as follows:
Figure 24: Controller assigned to a group
CLEAR GRP PARAM ?
--> OUTPUTS MUTED
Group parameters still available
Group pa
rameters
and outputs muted
*
OK
ESC
OK
ESC
65: SB28_60 110
SB_A SB_A SB_B SB_B
65: SB28_60 110
SB_A SB_A SB_B SB_B
*
LOAD
PRESET K1
11: K1
LOAD PRESET SB28
65: SB28_60
LOAD PRESET SB218
71: SB218_X
OK
ESC
LOAD
PRESET
ARE YOU SURE ?
OK
ESC
65: SB28_60 110
SB_A SB_A SB_B SB_B
