![L-ACOUSTICS KUDO Руководство по эксплуатации онлайн [25/52] 776314](/views2/2008029/page25/bg19.png)
KUDO_UM_ML_2-0
w w w . l - a c o u s t i c s . c o m
23
2323
23 en
EN
Weight 87 kg / 191.8 lbs
Shipping
L-ACOUSTICS
®
KPLA-2 dolly board (available as an option).
L-ACOUSTICS
®
KCOV protective cover (available as an option).
Vertical flying
2
L-ACOUSTICS
®
KBUMP rigging structure (available separately).
Certified for up to 21 KUDO
®
. Inter-element angles: 0°-10° in 1° steps.
Horizontal flying
2
L-ACOUSTICS
®
KLIFT rigging accessory (available separately).
Certified for up to 7 KUDO
®
per K-LIFT. Fixed inter-element angle: 10°.
Vertical stacking
2
L-ACOUSTICS
®
KBUMP rigging structure and KJACK rigging accessories
(available separately). Certified for up to 6 KUDO
®
.
Inter-element angles: 0°-10° in 1° steps.
External Structure
Material 15, 18, and 30 mm Baltic birch plywood.
Finish Grey Brown RAL 8019
®
or Pure White RAL 9010
®
.
Front Polyester-coated steel grill, acoustically transparent “Airnet” fabric.
Rigging Polyester-coated high-grade steel.
Handles Integrated into the cabinet.
1
Peak level measured at 1m under free field conditions using 10 dB crest factor pink noise with specified preset and corresponding EQ settings.
2
Installation safety limits are specified in the SOUNDVISION software which is designed to help with L-ACOUSTICS
®
product implementation.
