KUDO
KUDOKUDO
KUDO
®
®®
®
multi
multimulti
multi-
--
-m
mm
mode
ode ode
ode wst
wstwst
wst
®
®®
®
e
e e
enclosure
nclosurenclosure
nclosure
use
useuse
user
rr
r
manual
manualmanual
manual
VERSION 2.0
KUDO_UM_ML_2-0
w w w . l - a c o u s t i c s . c o m
6
66
6 en
4
44
4 KUDO
KUDOKUDO
KUDO
®
SYSTEM
SYSTEM SYSTEM
SYSTEM
The L-ACOUSTICS
®
KUDO
®
enclosure belongs to the KUDO
®
Line Source System and has an operating
frequency bandwidth from 35 Hz to 20 kHz. When operated in conjunction with the L-ACOUSTICS
®
SB118 or
SB28 subwoofer enclosure the combined system operating range is lowered down to 32 Hz and 25 Hz respectively.
The system approach developed by L-ACOUSTICS
®
for KUDO
®
consists of the elements needed to fully take
advantage of the possible configurations and optimize the system. The main components of the system are (see also
Figure 1 and Figure 2):
KUDO
®
Full range active 3-way WST
®
enclosure
KBUMP Rigging structure to fly or stack a KUDO
®
array in the vertical orientation
KJACKx2 Rigging accessories (x2) used with the KBUMP to stack a vertical array
KLIFT Rigging accessory to fly a KUDO
®
array in the horizontal orientation
KPLA-2, KCOV Front dolly board and protective cover to ship the KUDO
®
SB118, SB28 Subwoofer enclosures
LA-RAK Touring rack containing three LA8 amplified controllers
LA NETWORK MANAGER Remote control software
SOUNDVISION Acoustical and mechanical modeling software
The KUDO
®
system components are compatible with standard L-ACOUSTICS
®
accessories. These accessories include
the L-ACOUSTICS
®
DO.7, DO10, and DO25 loudspeaker cables with respective lengths of 0.7 m/2 ft,
10 m/30 ft, and 25 m/80 ft. These cables allow connection of the KUDO
®
enclosure to the LA8 amplified controller.
Each cable is an 8-conductor cable with 4 mm
2
conductor cross-section (13 SWG, 11 AWG) and features 8-point
PA-COM
®
connectors. Note: The PA-COM
®
and CA-COM
®
standards are fully compatible.
The KUDO
®
system is exclusively driven and powered by the L-ACOUSTICS
®
LA8 amplified controller. This ensures
intelligent protection, filtering, and equalization of the enclosures. Four channels of amplification are provided along
with the OEM factory preset library, ensuring the optimization and performance of the system within the limits of the
recommended configurations.
The L-ACOUSTICS
®
LA-RAK touring rack offers an advanced solution for all L-ACOUSTICS
®
systems covering signal
and power distribution in a comprehensive plug and play touring package. The LA-RAK was created as a universal
platform designed to facilitate cross-rental and to ensure compatibility with the L-ACOUSTICS
®
legacy analog cabling
standard.
Each system design configuration should first be modeled and studied using the L-ACOUSTICS
®
SOUNDVISION
software. The software predictions are based on the preset parameters stored in the amplified controllers.
Up to 253 amplified controllers can be interconnected and monitored through the proprietary L-ACOUSTICS
®
L-NET network using the L-ACOUSTICS
®
LA NETWORK MANAGER software.
Detailed description on using the LA8 amplified controller, SOUNDVISION and LA NETWORK MANAGER software is
beyond the scope of this manual. Please, refer to the applicable documentation available on the
L-ACOUSTICS
®
web site at
www.l-acoustics.com.
