KUDO
KUDOKUDO
KUDO
®
®®
®
multi
multimulti
multi-
--
-m
mm
mode
ode ode
ode wst
wstwst
wst
®
®®
®
e
e e
enclosure
nclosurenclosure
nclosure
use
useuse
user
rr
r
manual
manualmanual
manual
VERSION 2.0
KUDO_UM_ML_2-0
w w w . l - a c o u s t i c s . c o m
12
1212
12 en
A simple mechanical operation allows the user to configure each K-LOUVER
®
in the desired position: rotate both
K-LOUVER
®
latches and slide the K-LOUVER
®
towards interior (to obtain 55° coverage pattern) or towards exterior (25°
pattern) until the latches lock automatically (see Figure 6).
Figure 6: K-LOUVER
®
setting procedure
6.1.3 Stacking or flying the KUDO
®
The KUDO
®
fully integrated four-point rigging (Figure 3) features one rotating arm per side allowing to assemble
multiple enclosures with inter-enclosure angles from 0° to 10° in 1° increments. This allows various setups in flown or
stacked configurations such as:
•
Flying a vertical array of up to 21 KUDO
®
enclosures using the L-ACOUSTICS
®
KBUMP rigging structure
(see Figure 1).
•
Flying a horizontal array of up to 7 KUDO
®
enclosures per L-ACOUSTICS
®
KLIFT rigging accessory.
•
Stacking a vertical array of up to 6 KUDO
®
enclosures onto the L-ACOUSTICS
®
KBUMP rigging
structure, using the complimentary L-ACOUSTICS
®
KJACKx2 rigging accessories.
Refer to the “KUDO
®
’’ rigging procedures manual to get acquainted with the KUDO
®
system
specific rigging procedures.
!
WARNING
Two latches
mounted on each
K-LOUVER
®
K
-
LOUVER
®
Towards interior
Towards exterior
