To ensure both high performance and safety, L-ACOUSTICS
®
recommends the exclusive use of
high-quality, fully insulated speaker cables made of stranded copper wire.
In order to preserve a high damping factor it is desirable to keep loudspeaker cables as short as
possible and with a gauge offering low resistance per unit length.
The following table provides information regarding the recommended cable length versus conductor cross-section.
Three cases are possible depending on the impedance load connected to the LA8 (8 Ω for a single KUDO
®
enclosure,
4 Ω for two KUDO
®
enclosures in parallel, and 2.7 Ω for three KUDO
®
enclosures in parallel):
Table 1: Maximum cable length versus conductor cross-section for Damping Factor > 20
Cross-section Length for one KUDO
®
(8 Ω load)
Length for two KUDO
®
(4 Ω load)
Length for three KUDO
®
(2.7 Ω load)
mm
2
SWG
AWG
m ft m Ft m ft
2.5 15 13 30 100 15 50 10 33
4 13 11 50 160 25 80 17 53
6 11 9 74 240 37 120 25 80
10 9 7 120 390 60 195 40 130
According to the calculation in Table 1, one DO25 cable (4 mm², 25 m) can be used to power two KUDO
®
in parallel
(4 Ω load) with a damping factor still greater than 20.
!
