AMERICAN DJ Starburst [10/10] Auto sensing voltage
![AMERICAN DJ Starburst [10/10] Auto sensing voltage](/views2/2008150/page10/bga.png)
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Model: Starburst
Voltage: 100v~240v/ 50~60Hz
LEDs: 5 x 15W 6-in-1 HEX LED
Power Consumption: 55W
Power Cord Daisy Chain: 20 Fixtures Max.
Colors: RGBWYP
Beam Angle: 1 Degree
Dimensions: 12.5”(L) x 12.5”(W) x 16.25”(H)
318mm x 318mm x 412.5mm
Weight: 8 Lbs. / 3.65 Kgs
Fuse: 2 Amp
Duty Cycle: None
DMX: 12 DMX Channels
Working Position: Any Safe, Secure Position
Warranty: 1 Year (365 Days)
Starburst Specifications
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC - www.adj.com - Starburst Instruction Manual Page 18
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
