ADJ Products, LLC - www.adj.com - Starburst Instruction Manual Page 12
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to create unique programs tailored to your
individual needs. NOTE: AUTO Mode must be turned OFF before
DMX control can be used. Please see AUTO on page 6.
1. The Starburst is a 12 channel DMX fixture. See pages 13-14 for a
detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 6-8 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 9 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Starburst DMX Control
Master-Slave Operation This function will allow you to link up to 16
units together and operate without a controller. In a Master-Slave set
up one unit will act as the controlling unit and the others will react to the
controlling units programs. Any unit can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master press the MODE button until “ASte” is displayed
and press ENTER. Press the UP or DOWN buttons so that “MAST”
is displayed and press ENTER. The unit is now designated as the
Master. After you have designated it as the Master, find and run
your desired operating mode.
3. On the slave units press the MODE button until “ASte” is dis-
played and press ENTER. Press the UP or DOWN buttons so that
“ALon” is displayed and press ENTER. Now set the slave units to
DMX address setting. The slave units will now follow the Master.
Starburst Master-Slave Configuration
ADJ Products, LLC - www.adj.com - Starburst Instruction Manual Page 13
Starburst DMX Values & Traits
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 YELLOW
0 - 255 0% - 100%
6 PURPLE
0 - 255 0% - 100%
7 STROBING
0 - 7 OFF
8 - 15 LED ON
16 - 131 STROBING SLOW - FAST
132 - 139 LED ON
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 LED ON
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 LED ON
240 - 247 RANDOM STROBE
248 - 255 LED ON
8 MASTER DIMMER
0 - 255 0% - 100%
9 ROTATION
0 - 30 NO ROTATION
31 - 140 CLOCKWISE ROTATION FAST - SLOW
141 - 145 STOP
146 - 255 COUNTER-CLOWISE ROTATION
SLOW - FAST
10 COLOR MACROS
0 - 25 NO FUNCTION
26 - 205 COLOR MACROS
