DESCRIPTION

Congratulations! With buying a DYNACORD PowerSub 312 you have decided on getting one of

today’s most advanced active subwoofers incorporating most sophisticated technology.

The PowerSub 312 active 12” subwoofer with an integrated 3-channel power amplier provides a total

of 1300 watts output power. It has been specially designed for the quick and easy setup of a subwoofer

satellite system. Two passive loudspeaker systems like for example DYNACORD D8 are needed as

satellites, which are simply connected at the designated Speakon outputs of the PS312. Manufactured from

multi-ply wood the PowerSub 312 withstands even the hardest strain during transport and operation.

The integrated lightweight digital power amp with 800 W + 2 x 250 W output power optimally matches

the integrated DYNACORD DND 12S400 woofer offering highest dynamic and audio performance and

at the same time ensures that the DYNACORD DND 12S400 woofer is always operated in its optimum

operating range. Extensive protection circuitry like Voice Coil Protection, DC/HF-Protection, Audio Limiter,

Back-EMF Protection and Thermal Protection are employed to securely monitor the compliance to these

operating limits, which guarantees that the PowerSub 312 provides outstanding performance even under

most demanding and most unfavorable conditions. Compared to usual Class AB-operated amps the

utilized “Class D digital technology”, produces signicantly less power loss, reducing thermal stress of

all components. The enclosure is sealed with a scratch-resistant, hardwearing 2K-lacquer nish. A robust

powder-coated steel grille protects the DYNACORD DND12S400 woofer against mechanical damage.

All controls are recessed to provide optimum protection for the sensitive parts of the PowerSub 312 even

during transportation. Two stable carrying handles and an integrated threaded pole-mount ange allow

comfortable transportation and optimum, space saving installation.

Unpacking and Warranty

Open the packaging and carefully take out the PowerSub 312. Remove the protective foil from the carrying

handles. Mains cord and warranty card are supplied in addition to this owner’s manual. Please make sure

that all details are lled in on the warranty card. Only a completely lled in warranty certicate entitles you

to stake any warranty claims. Keep the original invoice together with the warranty card at a safe place.

Setup and Connections

Place the PowerSub 312 on an even ground, using the rubber feet to ensure safe and steadfast operation.

Make sure to check the stability of the system when using pole-mounts installed in the PowerSub 312. Do

not cover the subwoofer’s rear during operation. Otherwise, thermal overload could cause the PowerSub

312 to enter power reduction mode, which reliably protects the unit from being damaged. However, in

this mode full output power is not available. Mains power is supplied via Neutrik’s professional PowerCon

connector system and by use of an extremely long (5m) mains cord. This ensures absolute secure and

reliable connection to the mains outlet. Nevertheless, using high-quality mains distributors that allow high

power consumption and offer reliable protection throughout the entire system is strongly recommended

with large installations consisting of several active cabinets.

Before establishing the mains connection for the rst time, make sure that the cabinet’s

operating voltage setting, which can be found on a label next to the mains switch, corresponds

to your local mains network.
