AMERICAN DJ Inno Color Beam Z19 [7/14] Back light auto of
![AMERICAN DJ Inno Color Beam Z19 [7/14] Back light auto of](/views2/2008196/page7/bg7.png)
ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 13ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 12
2. Either “No Delay” or time between 1s - 3s will be displayed.
This number represents the delay setting. Use the UP and DOWN
buttons to adjust the blackout delay.
Example: If the delay is set to 3 seconds, when you are in 14
Channel mode under DMX control, and the channel 12 values are
between 226-235, the xture will move, and then blackout after
3 seconds.
3. Press ENTER to conrm.
White Balance - With this function you can adjust the
RGB colors to make your desired color.
1. Press the MENU button until “White Balance” is displayed,
press ENTER.
2. Use the UP or DOWN buttons to nd the color you wish to
adjust.
3. Once you nd the color you want to adjust press ENTER, the
displayed value will begin to ash. Use the UP or DOWN but-
tons to adjust the value. Once you have made your adjustment
press ENTER.
4. Repeat steps 2-3 until satised.
Manual Test - With this function you can manually test
the individual features.
1. Press the MENU button until “Manual Test” is displayed,
press ENTER.
2. Use the UP or DOWN buttons to nd the functions that you
wish to test.
3. Once you nd a function you wish to test, press the ENTER
button, the displayed value will begin to ash. You can now
adjust the values by pressing the UP and DOWN buttons. Once
Inno Color Beam Z19 System Menu Inno Color Beam Z19 System Menu
3. Press ENTER to set you desired level.
Pan Inverse - Pan Inversion
1. Press the MENU button until “Pan Inverse” is displayed,
press ENTER. Either “Yes” or “No” will be displayed.
2. To activate the Pan inversion press the UP or DOWN buttons
until “Yes” is displayed, press ENTER to conm. To deactivate
Pan inversion, select “No” and press Enter.
Tilt Inverse - Tilt Inversion
1. Press the MENU button until “Tilt Inverse” is displayed, press
ENTER. Either “Yes” or “No” will be displayed.
2. To activate the Tilt inversion press the UP or DOWN buttons
until “Yes” is displayed, press ENTER to conm. To deactivate
Tilt inversion, select “No” and press Enter.
Back Light Auto O - With this function you can make
the backlight automatically turn off after one minute.
1. Press the MENU button until “Back Light Auto O” is dis-
played, press ENTER.
2. Either “No” or “Yes” will now be displayed. Press the UP or
DOWN buttons to select “Yes” to keep the backlight on at all
times, or “No” to allow the backlight to turn o after 2 minutes.
Press any button to turn the backlight on again.
3. Press ENTER to conrm.
Function Delay - With this function the blackout func-
tion under 14 Channel mode can be delayed.
1. Press the MENU button until “Function Delay” is displayed,
press ENTER.
