ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 3ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 2
Inno Color Beam Z19 Warranty Registration
The Inno Color Beam Z19 carries a 2 year (730 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www.
americandj.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ customer sup-
port for a R.A. number.
Inno Color Beam Z19 Features
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this manual
with the unit, for future reference.
Inno Color Beam Z19 General Instructions
Inno Color Beam Z19 Introduction
Unpacking: Thank you for purchasing the Inno Color Beam Z19 by
ADJ Products, LLC. Every Inno Color Beam Z19 has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
xture for any damage and be sure all accessories necessary to oper-
ate the unit has arrived intact. In the case damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Do not return this unit to your dealer
without rst contacting customer support.
Introduction: The Inno Color Beam Z19 is part of ADJ’s continuing
pursuit for creating high quality affordable intelligent fixtures. The Inno
Color Beam Z19 is a high performance, DMX intelligent, moving head
LED fixture. This fixture is a great piece for retail stores, displays, mood,
architectural, interior and exterior decoration, and clubs. This unit can
be used as a stand alone, or in a Master/Slave conguration. The unit
can also be controlled via DMX controller. This fixture is suitable for
theaters, studios, retail stores, and other similar locations.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial operation.
You may also visit us on the web at www.adj.com for any comments
or suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
• RGBW Color Mixing
• 19 x 10W High Quatlity Osram Ostar Quad Color LEDs
• Color Strobe Effect
• Color Mix Effect
• Pan/Tilt Inversion
• Electronic Dimming 0-100%
• Dimmer Curve
• Built in Microphone
• DMX-512 protocol
• 14 DMX Channels
• 3 Operating Modes - Sound Active, Show Mode, & DMX Control
• Power Cord Daisy Chaining (See section below)
Inno Color Beam Z19 Power Cord Daisy Chaining
With this feature you can connect the xtures to one another
using the PowerCON input and output sockets. The quantity that
can be connected is 5 xtures maximum for 120V and 11 xtures
maximum for 240V. After the maximum xtures has been reached
you will need to use a new power outlet. They must be the same
xtures. DO NOT mix xtures.
