ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 14
ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 15
you have nished testing press the ENTER button.
4. To exit the manual test mode, press the MENU button.
Auto Test - This function will run a self test program.
1. Press the MENU button until “Auto Test” is displayed, press
ENTER.
2. The xture will now run a self test. Press the MENU button to
exit.
Fixture Use Time - With this function you can display
the running time of the unit.
1. Press the MENU button until “Fixture Use Time” is displayed,
press ENTER.
2. The running time of the xture will now be displayed. Press
MENU to exit.
Firmware Version - This will display the software ver-
sion
1. Press the MENU button until “Firmware Version” is displayed.
Press the ENTER button and the software vesion will be dis-
played.
2. Press the MENU button to leave this function.
PRO Default - This function will restore the factory set-
tings.
1. Press the MENU button until “PRO Default” is displayed,
press ENTER.
2. Either “YES” or “NO” will now be displayed. Press the UP or
DOWN buttons to select “YES” to switch back to defualt set-
Inno Color Beam Z19 System Menu
tings, and press ENTER.
Reset - Use this function to reset the motors.
1. Tap the MENU button until “Reset” is displayed, press
ENTER.
2. The xture will now reset the motors.
Inno Color Beam Z19 System Menu
