ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 11ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 10
Inno Color Beam Z19 System Menu
2. Press the UP or DOWN buttons until your desired mode is
displayed, press ENTER to conm.
NOTE: In a Master/Slave conguration you can make one x-
ture the Master and then set the next xture to “Slave 2”, the
xtures will now have contrast movement to each other.
Blackout - This will activate/deactivate blackout
1. Press the MENU button until “Blackout” is displayed, press
ENTER.
2. Either “Yes” or “No” will now be displayed. Press the UP or
DOWN buttons to toggle between “Yes” and “No”.
3. Press ENTER to conrm your setting.
Sound State - In this mode the unit will run in sound
active mode.
1. Press the MENU button until “Sound State” is displayed, press
ENTER.
2. Either “On” or “O” will now be displayed. Use the UP or
DOWN buttons to toggle between “On” and “O”.
3. Press ENTER to conrm your selection, the press and hold the
MENU button to activate.
Sound Sense - In this mode you can adjust the sound
sensitivity of the sound active mode.
1. Press the MENU button until “Sound Sense” is displayed,
press ENTER.
2. Press the UP or DOWN buttons to adjust the sensitivity level.
The sensitivity level can be adjusted between 0 (the lowest) and
100 (most sensitive).
Inno Color Beam Z19 System Menu
DMX Address - Set the DMX Address -
1. Press the MENU button until “DMX Addresss” is displayed,
press ENTER.
2. “X” will now be displayed, “X” represents the displayed address.
Press the UP or DOWN buttons to nd your desired address.
3. Press ENTER to conrm, and then press and hold the MENU
button for at least three seconds to assign.
Show Mode - Show modes 1 - 4 (Factory Shows).
1. Press the MENU button until “Show Mode” is displayed, press
ENTER.
2. “Show X” will now be displayed, “X” representing a number
between 1-4. Press the UP or DOWN buttons to nd your desired
show and press ENTER to conrm. After pressing ENTER, press
and hold the MENU button for at least 3 seconds to activate.
Dimmer Curve - In this mode you can select the dimmer
curve.
1. Press the MENU button until “Dimmer Curve” is displayed,
press ENTER.
2. The current dimmer curve will be displayed.
3. Press the UP or DOWN buttons to nd your desired dimmer
curve and press ENTER to conrm.
Slave Mode - This will let you set unit as a master or
slave in a master/slave conguration.
1. Press the MENU button until “Slave Mode” is displayed,
press ENTER. Either “Master”, “Slave 1” or “Slave 2” will be
displayed.
