AMERICAN DJ Fusion TRI FX Bar [4/10] Shnd sh 0 sh 1

Fusion Tri FX Bar System Menu Fusion Tri FX Bar System Menu

ADDR - DMX Address Setting via control board -

1. Tap the MENU button until “ADDR” is displayed, press ENTER.

2. “X” will now be displayed, “X” represents the displayed address.

Press the UP or DOWN buttons to nd your desired address.

3. Press ENTER to conrm, and then press and hold the MENU button

for at least three seconds to assign.

SLND - This will let you set unit as a master or slave in a

master/slave conguration.

1. Tap the MENU button until “SLND” is displayed, press ENTER.

Either “MAST”, “SL 1” or “SL 2” will be displayed.

2. Tap the UP or DOWN buttons until your desired setting is dis-

played, press ENTER to conm.

NOTE: In a Master/Slave conguration you can make one xture the

Master and then set the next xture to “SL 2”, the xtures will now

have contrast movement to each other.

SHND: SH 0 - SH 16 - Show modes 0 - 16 (Factory pro-

grams). You can run show mode with sound active mode off

On-Board System Menu.

The Fusion Tri FX Bar comes with an easy

to navigate system menu. This next section will detail the functions of

each command in the system menu. Please read the next section

thoroughly!

To access the main menu press the MENU button. Tap the UP or

DOWN buttons until you reach function you wish to change. When you

reach the function you wish to change press the ENTER button. When

a function is selected use the UP or DOWN buttons to change the func-

tion settings. Once your changes are made press the ENTER button,

and then press and hold the MENU button for at least three seconds

to conrm and lock the change into the system memory. If the MENU

button is not pressed and held within eight seconds the xture will

automatically conrm and lock the change into the system memory. To

exit without making any changes press the MENU button.

©American DJ Supply® - www.americandj.com - Fusion Tri FX Bar - Page 7 ©American DJ Supply® - www.americandj.com - Fusion Tri FX Bar - Page 8
