![AMERICAN DJ Fusion TRI FX Bar [5/10] In this mode you can run the unit in sound active mode](/views2/2008197/page5/bg5.png)
Fusion Tri FX Bar System Menu Fusion Tri FX Bar System Menu
or on.
1. Tap the MENU button until “SHND” is displayed, press ENTER.
2. “Sh X” will now be displayed, “X” representing a number between 1-
16. Shows 1-16 are preset shows, while “Sh 0” is random show. Press
the UP or DOWN buttons to nd your desired show.
3. Press ENTER, and then press and hold the MENU button for at least
3 seconds to conrm.
SOUN - In this mode you can run the unit in sound active
mode
1. Tap the MENU button until “SOUN” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. When you have made your selection, press the ENTER, and then
press and hold the MENU button for at least 3 seconds to conrm.
BLND - This will control blackout
1. Tap the MENU button until “bLNd” is displayed, press ENTER.
2. Either “YES” or “NO” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
LED - With this function the LED display will turn off after 2
minutes.
1. Tap the MENU button until “LED” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select “ON” to keep the LED display on at all times, or “OFF”
to allow the LED display to turn o after 2 minutes. Press any button to
turn on the LED display again.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
DISP - This will “ip” the LED display
1. Tap the MENU button until “dISP” is displayed, press ENTER.
2. Either “dISP” or “dSIP” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
MANU - With this function you can manually test the indi-
vidual features.
1. Tap the MENU button until “MANU” is displayed, press ENTER.
2. Press the UP or DOWN buttons to nd and manually test the indi-
vidual features. Press ENTER when you have found the feature you
want to test.
TEST - This function will run a self test program.
1. Tap the MENU button until “TEST” is displayed, press ENTER.
2. The xture will now run a self test.
FHRS - With this function you can display the running time
of the unit.
1. Tap the MENU button until “FHRS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VER - This will display the software version
1. Tap the MENU button until “VER” is displayed. Press the ENTER
button and the software vesion will be displayed.
2. Press the MENU button to leave this function.
