Fusion Tri FX Bar UC3 Control

Fusion Tri FX Bar Operation Fusion Tri FX Bar Operation

Universal DMX Control: This function allows you to use a Elation®

universal DMX-512 controller to control the chases and patterns, dim-

mer and strobe. A DMX controller allows you to create unique pro-

grams tailored to your individual needs.

1. The Fusion Tri FX Bar is a 8 DMX channel unit. See page 13 for a

detailed description of the DMX traits.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included

with your DMX controller.

Master-Slave Operation: This function will allow you to link up to 16

units together and operate without a controller. In Master-Slave opera-

tion one unit will act as the controlling unit and the others will react to

the controlling units programs. Any unit can act as a Master or as a

Slave.

1. Using standard XLR microphone cables, daisy chain your units

2. On the Master unit find your desired show or choose sound act-

tive mode and set that by pressiing the ENTER button.

3. On the slave units tap the MENU button until “SLND” is display-

ed, and Press ENTER.

4. The slave units will now follow the Master unit.

5. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

linked together, to run to the beat of the music.

1. Tap the MENU button until “SOUN” is displayed, and press

together, to run your desired factory show.

1. Tap the MENU button until “SHND” is displayed, and press

ENTER.

2. Tap the UP or DOWN buttons until you nd your desired show,

and press ENTER, and then press and hold the MENU button to

conrm.

3. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.
