![AMERICAN DJ Fusion TRI FX Bar [8/10] Fusion tri fx bar cleaning](/views2/2008197/page8/bg8.png)
©American DJ Supply® - www.americandj.com - Fusion Tri FX Bar - Page 15
Fusion Tri FX Bar Warranty
MANUFACTURER’S LIMITED WARRANTY
A. American DJ, Inc. hereby warrants, to the original purchaser, American DJ and American
Audio products to be free of manufacturing defects in material and workmanship for a prescribed
period from the date of purchase (see specic warranty period on reverse). This warranty shall be
valid only if the product is purchased within the United States of America, including possessions
and territories. It is the owner’s responsibility to establish the date and place of purchase by ac-
ceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before
sending back the product. Contact American DJ, Inc. Service Department at 800-322-6337. Send
the product only to the American DJ, Inc. factory. All shipping charges must be pre-paid. If the
requested repairs or service (including parts replacement) are within the terms of this warranty,
American DJ, Inc. will pay return shipping charges only to a designated point within the United
States. If the entire instrument is sent, it must be shipped in it’s original package. No accessories
should be shipped with the product. If any accessories are shipped with the product, American DJ,
Inc. shall have no liability whatsoever for loss of or damage to any such accessories, nor for the
safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is
modied in any manner which American DJ, Inc. concludes, after inspection, aects the reliability
of the product; if the product has been repaired or serviced by anyone other than the American DJ,
Inc. factory unless prior written authorization was issued to purchaser by American DJ, Inc.; if the
product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning
or periodic check-up. During the period specied above, American DJ, Inc. will replace defective
parts at its expense with new or refurbished parts, and will absorb all expenses for warranty service
and repair labor by reason of defects in material or workmanship. The sole responsibility of Ameri-
can DJ, Inc. under this warranty shall be limited to the repair of the product, or replacement thereof,
including parts, at the sole discretion of American DJ. All products covered by this warranty were
manufactured after January 1, 1990, and bear identifying marks to that eect.
E. American DJ, Inc. reserves the right to make changes in design and/or improvements
upon its products without any obligation to include these changes in any products theretofore man-
ufactured. No warranty, whether expressed or implied, is given or made with respect to any acces-
sory supplied with products described above. Except to the extent prohibited by applicable law, all
implied warranties made by American DJ, Inc. in connection with this product, including warranties
of merchantability or tness, are limited in duration to the warranty period set forth above. And no
warranties, whether expressed or implied, including warranties of merchantability or tness, shall
apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy
shall be such repair or replacement as is expressly provided above; and under no circumstances
shall American DJ, Inc. be liable for any loss or damage, direct or consequential, arising out of the
use of, or inability to use, this product.
This warranty is the only written warranty applicable to American DJ and American Audio
Products and supersedes all prior warranties and written descriptions of warranty terms and
conditions heretofore published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
• All American Audio Products = 1-year (365 day) Limited Warranty (except V-Plus Series Ampli-
ers)
• All American Audio V-Plus Series Ampliers = 3-year (1095 day) Limited Warranty
• American DJ Lighting and American DJ Branded Products = 1-year (365 day) Limited Warranty
(Such as: Special Eect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble
Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc. excluding Laser Products, lamps,
and Star Tec Series)
• American DJ Laser Products and Star Tec Products = 90-Day Limited Warranty
• American DJ L.E.D. Products = 3-year (1095 day) Limited Warranty (excluding motors which have
a 1-year (365 day Limited Warranty)
Fusion Tri FX Bar Cleaning
Due to fog residue, smoke, and dust cleaning the internal and exter-
nal optical lenses must be carried out periodically to optimize light
output.
1. Use a soft cloth to wipe down the outside casing.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
If problems are not resolved; Contact American DJ® for service.
1-800-322-6337
Fusion Tri FX Bar Trouble Shooting
First unplug the power. The fuse holder is located next to the power
inlets. Using a flat-head screw driver unscrew the fuse holder.
Remove the bad fuse and replace with a new one.
Fusion Tri FX Bar Fuse Replacement
©American DJ Supply® - www.americandj.com - Fusion Tri FX Bar - Page 16
Fusion Tri FX Bar 12 Degree Lens
To switch to the 12 Degree lens, simply unscrew and remove the
phillips screws located above and below the lenses. After the screws
have been removed, remove frame that holds the lens in place.
Remove the lens and install the 12 Degree lens. Put the lens frame
back into place, and replace the phillips screws to secure the frame
and lens.
