STRIKE P38 User Manual Rev. 1
Operation
4. Operation
Control Panel Operation
Control Options
Set the STRIKE P38 starting address in the 001–512 DMX range. This enables control of up to 85
products in the 6-channel 6 Ch personality.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will take you to the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until
the option shows on the display. Press <ENTER> to select. In this case, if there is another
programming level, you will see that first option, or you will see the selected value.
• Press <MENU> repeatedly to exit to the previous main level.
Menu Map
Button Function
<MENU> Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected value in to the current function
<UP> Navigates upward through the menu list or increases the numeric value when in a function
<DOWN> Navigates downward through the menu list or decreases the numeric value when in a function
Main Level Programming Levels Description
DMX Address Address <001–510>
Selects DMX address (highest channel restricted to
personality chosen)
DMX
Personality
3 Ch 3-channel: dimmer, red shift, dimmer speed
4 Ch 4-channel: 16-bit dimmer, red shift, dimmer speed
5 Ch 5-channel: dimmer, red shift, strobe, auto, dimmer speed
6 Ch
6-channel: 16-bit dimmer, red shift, strobe, auto, dimmer
speed
Static
Dimmer
<0–255>
Controls intensity
Strobe Controls strobe rate
Auto Show Auto 1–3 <001–100> Automatic programs
Red Shift
On
Turns on or off Red Shift (Amber LEDs imitate lamp
when dimming)
Off
Master/Slave
Mode
Master DMX mode (Master)
Slave Slave mode
Dimmer Mode
Off Linear dimmer
Dimmer 1–3 Dimming curves Dimmer 1 (fast) to Dimmer 3 (slow)
LED
Frequency
600Hz
Sets the PWM frequency
1200Hz
2000Hz
4000Hz
6000Hz
25KHz
Back Light
On Display backlight always on
10S Turns off display backlight after 10 seconds of inactivity
20S Turns off display backlight after 20 seconds of inactivity
30S Turns off display backlight after 30 seconds of inactivity
Key Lock
On
Locks display (password is <UP>, <DOWN>, <UP>,
<DOWN>, <ENTER>)
Off
