Page 9 of 16
STRIKE P38 User Manual Rev. 1
Operation
DMX Values
6 Ch
5 Ch
Channel Function Value Percent/Setting
1 Dimmer 000
255 0–100%
2 Fine Dimmer 000
255 0–100%
3Red Shift
000 On
001
255 Off
4Strobe
000
010 No function
011
255 Strobe, slow to fast
5 Auto Program
000
010 No function
011
080 Auto 1, slow to fast
081
160 Auto 2, slow to fast
161
240 Auto 3, slow to fast
241
255 No function
6 Dimmer Speed*
000
051 Current dimmer speed mode
052
101 Dimmer speed mode off (linear dimmer)
102
152 Dimmer speed mode 1 (fastest)
153
203 Dimmer speed mode 2
204
255 Dimmer speed mode 3 (slowest)
Channel Function Value Percent/Setting
1 Dimmer 000
255 0–100%
2Red Shift
000 On
001
255 Off
3Strobe
000
010 No function
011
255 Strobe, slow to fast
4 Auto Program
000
010 No function
011
080 Auto 1, slow to fast
081
160 Auto 2, slow to fast
161
240 Auto 3, slow to fast
241
255 No function
5 Dimmer Speed*
000
051 Current dimmer speed mode
052
101 Dimmer speed mode off (linear dimmer)
102
152 Dimmer speed mode 1 (fastest)
153
203 Dimmer speed mode 2
204
255 Dimmer speed mode 3 (slowest)
*Hold desired dimmer speed value for 3 seconds, then release. This changes the
dimmer speed setting in the menu.
