Technical Specifications

6. Technical Specifications

Dimensions and Weight

Note: Dimensions in inches rounded to the nearest decimal digit.

Power

Light Source

Photometrics

Thermal

DMX

Ordering

Length Width Height Weight

11.93 in (303 mm) 10.27 in (261 mm) 7.25 in (184 mm) 8.4 lb (3.8 kg)

Power Supply Type Range Voltage Selection

Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging

Parameter 120 V, 60 Hz 208 V, 60 Hz 230 V, 50 Hz

Consumption 54 W 56 W 58 W

Operating Current 0.449 A 0.267 A 0.245 A

Power linking current

(products)

13.6 A (30 products) 13.6 A (50 products) 13.6 A (55 products)

Power I/O U.S./Worldwide UK/Europe

Power input connector Seetronic Powerkon A Seetronic Powerkon A

Power output connector Seetronic Powerkon B Seetronic Powerkon B

Power Cord plug Edison (U.S.) Local Plug

Type Color Quantity Power Current Lifespan

LED Warm white 1 80 W 1.19 A 50,000 hours

LED Amber 8 5 W 0.07 A 50,000 hours

Parameter Value

Color Temperature (at full) 2754 K

Color Temperature (at 10%) 1899 K

Beam Angle 27°

Field Angle 51°

Illuminance @ 5 m 325 lux

Maximum External Temperature Cooling System

113 °F (45 °C) Convection

I/O Connector Channel Range

5-pin XLR 3, 4, 5 or 6

Product Name Item Name Item Code UPC Number

STRIKE P38 STRIKEP38 03051454 781462218027
