CHAUVET Strike P38 [12/20] Operation

Page 8 of 16

Operation

STRIKE P38 User Manual Rev. 1

Configuration (DMX)

Use control configurations to operate the product with a DMX controller.

Control Personalities

This setting allows you to choose a particular control personality.

1. Go to the DMX Personality main level.

2. Select the desired personality (see table below).

Starting Address

Each product will respond to a unique starting address from the DMX controller. All products with the same

starting address will respond in unison.

1. Go to the DMX Address main level.

2. Select the starting address (001–512).

The highest recommended starting address for each DMX mode is as follows:

Information

Fixture Hours <_ _ _ _H> Shows total hours the product has been on

Version <V_._> Shows current firmware version

UID

<_ _ _ _ _ _ _

Shows product UID

Reset Factory

Resets the product to factory default settings

Yes

Personality Channels

3 Ch 3

4 Ch 4

5 Ch 5

6 Ch 6

• See the Starting Address

section for the highest starting address you can select for each

personality.

• Make sure that the starting addresses on the various products do not overlap due to the

new personality setting.

Personality Address

3 Ch 510

4 Ch 509

5 Ch 508

6 Ch 507

Main Level Programming Levels Description
