Руководство по эксплуатации Страница: 11

ADJ Royal 3D Руководство по эксплуатации онлайн [11/12] 776834

©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 21 ©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 22

Royal 3D Notes Royal 3D Notes

Содержание

Caution 1
Customer support 1
Introduction 1
Unpacking 1
User instructions 1
Warning 1
Operation instructions and laser safety 3
Stop and read all laser safety data 3
Dmx 512 4
Power supply 4
Be sure to follow figures two and three when making your own cables do not use the ground lug on the xlr connector do not con nect the cable s shield conductor to the ground lug or allow the shield conductor to come in contact with the xlr s outer casing grounding the shield could cause a short circuit and erratic behavior 5
Conductor 5 pin xlr male in 3 pin xlr female out 5
Data compliment signal 5
Data true signal 5
Dmx cable must be daisy chained and cannot be split 5
Ground shield 5
Not used 5
Notice 5
Pin 4 do not use 5
Pin 5 do not use 5
Pin xlr dmx connectors 5
Pin xlr to 5 pin xlr conversion 5
Royal 3d set up 5
Some manufactures use 5 pin dmx 512 data cables for data transmission in place of 3 pin 5 pin dmx fixtures may be implemented in a 3 pin dmx line when inserting stan dard 5 pin data cables in to a 3 pin line a cable adaptor must be used these adaptors are readily available at most electric stores the chart below details a proper cable conversion 5
Special note line termination 5
When longer runs of cable are used you may need to use a terminator on the last unit to avoid erratic behavior a terminator is a 110 120 ohm 1 4 watt resistor which is con nected between pins 2 and 3 of a male xlr connector data and data this unit is inserted in the female xlr connector of the last unit in your daisy chain to terminate the line using a cable terminator adj part number z dmx t will decrease the possibilities of erratic behavior 5
Dmx address setting via control board 6
In this mode you can run in sound active mode 6
System menu when confirming your setting press enter and then hold menu for at least 2 3 seconds or you can wait 1 minute for automatic setup to exit without making any adjustments press the menu button 6
This will let you set unit as a slave in a master slave configuration 6
Sound sensitivity control 7
This function will flip the led display 180º 7
This function will run a self test program 7
This will control blackout 7
This will display the software version 7
Use this function to reset the unit 7
With this function the led display will turn off after 2 minutes 7
With this function you can display the running time of the unit 7
Master slave configuration 8
Operating modes the royal 3d has two different operating modes 8
Sound active mode stand alone or master slave 8
Universal dmx control 8
Always be sure to dry all parts completely before plugging the unit back in 10
American d 10
Be sure the fuse holder is completely and properly seated 4 be sure the unit is not in blackout mode unit does not respond to sound 10
Be sure you have turned on the unit 2 be sure the external fuse has not blown the fuse is located on the rear panel of the unit 10
Clean the external optics with glass cleaner and a soft cloth every 20 days 10
Cleaning frequency depends on the environment in which the fixture operates i e smoke fog residue dust dew in heavy use we recom mend cleaning on a monthly basis periodic cleaning will ensure lon gevity and crisp beam output 10
Due to fog residue smoke and dust cleaning the internal and external lenses should be carried out periodically to optimize light output 1 use normal glass cleaner and a soft cloth to wipe down the out side casing 10
Fixture cleaning 10
Locate and remove the unit s power cord once the cord has been removed located the fuse holder located inside the power socket insert a flat head screw driver into the power socket and gently pry out the fuse holder remove the bad fuse and replace with a new one the fuse holder has a built in socket for a spare fuse be sure not to confuse the spare fuse with active fuse 10
Low frequencies bass should cause the unit to react to sound tapping on the microphone quiet or high pitched sounds may 10
No laser output from the unit 10
Not activate the unit not activate the unit 10
Royal 3d cleaning 10
Royal 3d fuse replacement 10
Royal 3d trouble shooting 10
Royal 3d warranty 10
Trouble shooting listed below are a few common problems that you may encounter with solutions 10
Www americandj com royal 3d instruction manual page 19 10
Www americandj com royal 3d instruction manual page 20 10
American dj europe 12
American dj supply 12
American dj world headquarters 12
Auto sensing voltage 12
Ew kerkrade 12
Junostraat 2 12
Model royal 3d 12
Netherlands 12
Please note 12
S eastern ave los angeles ca 90040 usa 12
Service adjgroup eu www americandj eu 12
Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 12
Tel 31 45 546 85 00 fax 31 45 546 85 99 12
Tel 323 582 2650 fax 323 582 2610 12
This fixture contains a automatic volt age switch which will auto sense the voltage when it is plugged into the power source 12
Web www americandj com e mail info americandj com 12
Www maxlight ru 12
