ADJ Royal 3D [12/12] Netherlands
![ADJ Royal 3D [12/12] Netherlands](/views2/2008549/page12/bgc.png)
Model: Royal 3D
Voltage: 100-240V, 50/60Hz
Power Cord Daisy Chain: 14 Fixtures Max.
Power Consumption: 24W
Lasers: 30mW Green Diode
350mW Violet Blue Diode
Beam Angle: 90 Degrees
Dimensions: 8.75”(L) x 8”(W) x 7.75”(H)
222mm x 205mm x 194mm
Colors: Green & Violet Blue
Weight: 7 Lbs. / 3.2 kgs.
Fuse: 7 Amp
Duty Cycle: None
DMX: 5 DMX Channels
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 90 Days
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Royal 3D Specifications
©American DJ Supply
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-582-2610
Web: www.americandj.com / E-mail: info@americandj.com
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adjgroup.eu / www.americandj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 23
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
