ADJ Royal 3D [8/12] Master slave configuration
![ADJ Royal 3D [8/12] Master slave configuration](/views2/2008549/page8/bg8.png)
©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 15 ©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 16
CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the
audience.
Operating Modes: The Royal 3D has two different operating
modes.
Universal DMX Control: This function allows you to use a Elation®
universal DMX-512 controller to control the individual lasers, rotation,
and macros. A DMX controller allows you to create unique programs
tailored to your individual needs.
1. The Royal 3D is a five channel DMX fixture. See pages 17-18 for
detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 8-10 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instruction on page 11 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode (Stand Alone or Master-Slave): This mode
allows either single unit or several units linked together, to run to the
beat of the music.
1. Press the MENU button until “SOUN” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons so that “ON” is displayed, and
press ENTER to conrm and then hold MENU for at least 2-3 sec-
onds.
3. To adjust the sound sensitivity press the MENU button until
“SOSE” is displayed and press ENTER. Use the UP or DOWN but-
tons to adjust sensitivity.
4. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout. See page 16 for UC3
controls and functions.
Royal 3D Operation
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 14 xtures maximum. After 14 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Royal 3D Power Cord Daisy Chain
Master-Slave Conguration: This function will allow you to link
up to 16 units together and operate without a controller. The units will
be sound activated. In Master-Slave operation one unit will act as the
controlling unit and the others will react to the controlling units pro-
grams. Any unit can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. Set your Master unit to sound active mode.
3. On the slave units press the MENU button until “SLNd” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER. See page 12 for more info.
4. The slave units will now follow the Master unit.
Royal 3D Master-Slave Configuration
Royal 3D UC3 Control
Stand By Blackout the unit
Function 1. Strobe Blue
2. Strobe Green
3. Strobe in Green/Blue
Speed
1-3
Mode Sound (LED OFF) Rotation Speed(LED ON)
