ADJ Royal 3D [7/12] This function will run a self test program
![ADJ Royal 3D [7/12] This function will run a self test program](/views2/2008549/page7/bg7.png)
©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 14©American DJ® - www.americandj.com - Royal 3D Instruction Manual Page 13
SOSE - Sound sensitivity control.
1. Press the MENU button until “SOSE” is displayed, press ENTER.
2. The display will show a number between 0-100. Press the UP or
DOWN buttons to adjust the sound sensitivity. 0 being the least sen-
sitive and 100 the most sensitive.
3. Press the ENTER to conrm.
BLNd - This will control blackout
1. Press the MENU button until “BLNd” is displayed, press ENTER.
2. Either “YES” or “NO” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
LEd - With this function the LED display will turn off after 2
minutes.
1. Press the MENU button until “LEd” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select “ON” to keep the LED display on at all times, or “OFF”
to allow the LED display to turn off after 2 minutes. Press any button to
turn on the LED display again.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
dISP - This function will “ip” the LED display 180º.
1. Press the MENU button until “dISP” is displayed, press ENTER.
2. Either “dISP” or “dSIP” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
Royal 3D System Menu Royal 3D System Menu
TEST - This function will run a self test program .
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The unit will now run a self test. Press the MENU button to exit.
FHrS - With this function you can display the running time
of the unit.
1. Press the MENU button until “FHrS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VEr - This will display the software version
1. Press the MENU button until “VEr” is displayed. Press the ENTER
button and the software vesion will be displayed.
2. Press the MENU button to leave this function.
rSET - Use this function to reset the unit.
1. Tap the MENU button until “rSET” is displayed, press ENTER.
2. The xture will now reset.
