User’s Guide M-32 DA © RME
43
19.3 Table
No. No. Name
Set
Val.
Val.
Resp. Data bytes
00h 0 settings byte 1 x x hex coded value of byte (see below)
01h 1 settings byte 2 x x hex coded value of byte (see below)
02h 2 settings byte 3 x x hex coded value of byte (see below)
03h 3 info byte 1 x hex coded value of byte (see below)
04h 4 info byte 2 x hex coded value of byte (see below)
05h 5 info byte 3 x hex coded value of byte (see below)
06h 6 info byte 4 x hex coded value of byte (see below)
07h 7 level ch 01 x (see below)
08h 8 level ch 02 x (see below)
09h 9 level ch 03 x (see below)
0Ah 10 level ch 04 x (see below)
0Bh 11 level ch 05 x (see below)
0Ch 12 level ch 06 x (see below)
0Dh 13 level ch 07 x (see below)
0Eh 14 level ch 08 x (see below)
0Fh 15 level ch 09 x (see below)
10h 16 level ch 10 x (see below)
11h 17 level ch 11 x (see below)
12h 18 level ch 12 x (see below)
13h 19 level ch 13 x (see below)
14h 20 level ch 14 x (see below)
15h 21 level ch 15 x (see below)
16h 22 level ch 16 x (see below)
17h 23 level ch 17 x (see below)
18h 24 level ch 18 x (see below)
19h 25 level ch 19 x (see below)
1Ah 26 level ch 20 x (see below)
1Bh 27 level ch 21 x (see below)
1Ch 28 level ch 22 x (see below)
1Dh 29 level ch 23 x (see below)
1Eh 30 level ch 24 x (see below)
1Fh 31 level ch 25 x (see below)
20h 32 level ch 26 x (see below)
21h 33 level ch 27 x (see below)
22h 34 level ch 28 x (see below)
23h 35 level ch 29 x (see below)
24h 36 level ch 30 x (see below)
25h 37 level ch 31 x (see below)
26h 38 level ch 32 x (see below)
27h 39 fan control x (see below)
28h 40 temperature x (see below)
29h 41 (reserved) x
30h 42 (reserved) x
31h 43 set device id x (response displays in header)
