➤ Remove sliding piece (c), actuation
bar (d), compression spring (e) and
spring guide (f) from the magazine
housing. Take off the magazine hous-
ing. Blow out all parts with compressed
air. Remove major debris, e.g., with a
cloth. Especially clean the recess (d1) in
the actuation bar (d), as this could lead
to malfunctions of the magazine. Do
not use water for the cleaning; do not
apply oil or lubricate.
Assembling the disassembled magazine
holder
➤ Slide the dismounted and cleaned mag-
azine housing over the screwdriver bit
and place onto the spindle collar of the
driving tool to the stop.
➤ Press the roll (g) outwards and position
the switching strip (d) into the guide in
the middle between the stop and the
roll (g).
➤ Place the pressure spring (e) into the
sliding piece.
➤ Insert the spring guide (f) into the pres-
sure spring (e) as shown in the figure.
➤ Insert the complete assembled compo-
nents in the magazine housing and hold
tightly.
➤ Press back the switching strip (d) on
the outside as far as the stop until it
notches automatically in the magazine
housing. If necessary, press the release
knob (2) to notch the switching
strip (d).
➤ After the switching strip (d) has
notched in the magazine housing, let go
of the sliding piece (c) again.
Maintenance and repairs.
Risk of injury
Service, testing and repairs may only be car-
ried out by electrical engineers in conformity
with the regulations valid in the respective
country.
Maintenance and repairs.
For repairs, we recommend our FEIN cus-
tomer service centre, the FEIN authorised
service centres and FEIN agencies.
When carrying out your own repairs by
qualified electricians we supply the repair
documentation upon request.
Repairs may only be carried out by quali-
fied electricians in conformity with the
valid regulations.
Please always hand this Instruction Manual
to the those carrying out the repair.
Accessories.
Only use accessories recommended by
FEIN.
Warranty and liability.
The warranty for the product is valid in
accordance with the legal regulations in
the country where it is marketed.
In addition, FEIN also provides a guarantee
in accordance with the FEIN manufac-
turer’s guarantee. For further details on
this, please contact your specialist dealer,
your national FEIN representative, or the
FEIN customer service centre.
!
