To turn off the heater and air conditioner, push
the “OFF” button.
Cooling and dehumidified heating
1. Push the “AUTO” button.
(The AUTO indicator light will illuminate
and “AUTO” will appear on the display.)
2. If the A/C indicator light does not illumi-
nate, push the “A/C” button.
(The A/C indicator light will illuminate.)
3. Turn the temperature control dial (driver’s
side) to set the desired temperature.
● The temperature can be set within the
following range.
– For U.S.: 60 to 90°F (16 to 32°C)
– For Canada: 64 to 90°F (18 to 32°C)
● When the DUAL indicator light is turned
off:
– Pushing the driver’s side “AUTO” but-
ton changes both the driver’s and front
passenger’s side temperature.
– Pushing the passenger’s side “DUAL”
button changes only the front passen-
ger’s side temperature. (The DUAL indi-
cator light will illuminate and “DUAL”
will appear on the display.)
● To set separate desired temperatures for
the driver and front passenger, push the
“DUAL” button, the indicator light illumi-
nates, and then turn the corresponding
temperature control dial.
●
To cancel the separate temperature setting,
push the “DUAL” button, the indicator light
turns off, and the driver’s side temperature
setting will be applied to both the driver’s
and front passenger’s sides.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the air is
cooled rapidly. This does not indicate a mal-
function.
Heating (A/C off)
1. Push the “AUTO” button.
(The AUTO indicator light will illuminate
and “AUTO” will appear on the display.)
2. If the A/C indicator light illuminates, push
the “A/C” button.
(The A/C indicator light will turn off.)
3. Turn the temperature control dial to set
the desired temperature.
● When the DUAL indicator light is turned
off:
– Pushing the driver’s side “AUTO” but-
ton changes both the driver’s and front
passenger’s side temperature.
–
Pushing the passenger’s side “DUAL”
button changes only the front passen-
ger’s side temperature. (The DUAL indi-
cator light will illuminate and “DUAL”
will appear on the display.)
● To set separate desired temperatures for
the driver and front passenger, push the
“DUAL” button, the indicator light illumi-
nates, and then turn the corresponding
temperature control dial.
●
To cancel the separate temperature setting,
push the “DUAL” button, the indicator light
turns off, and the driver’s side temperature
setting will be applied to both the driver’s
and front passenger’s sides.
● Do not set the temperature lower than the
outside air temperature. Doing so may
cause the temperature not to be con-
trolled properly.
● If the windows fog up, use dehumidified
heating instead of the A/C off heating.
Dehumidified defrosting/defogging
1. Push the “ ” button. (The indicator
light will illuminate.)
2. Turn the temperature control dial to set
the desired temperature.
4-32 Monitor, climate, audio, phone and voice recognition systems
