Confidence Error - “0” indicates no problem. “1” indicates the PCM96

Surround is detecting excessive jitter or noise on the digital audio line.

No data has been corrupted, but corrective action should be taken.

Sample Slip - An unchanging number indicates you are not slipping

samples. An increasing number indicates samples are misaligned with

the window defined by the Input Source. This may occur when an

external master changes sample rate, or when it is just powering up, but

should not occur in normal operation.

Bi-Phase Error - “0” indicates no problem. “1” indicates that at least

one bit (and therefore at least one audio sample) was corrupted.

CRC Error - “0” indicates no problem. “1” indicates a Cyclic

Redundancy Check error in the incoming data.

Parity Error - “0” indicates no problem. “1” indicates that at least one

bit (and therefore at least one audio sample) was corrupted.

MaChine Config

The Machine Config menu lets you configure the PCM96 Surround proces-

sor as one, two, three, or four virtual machines in a new preset. Note that

once you’ve selected a configuration, you must then populate each virtual

machine with a Machine Preset (see page 11 for more information).

Choices include:

Single Stereo (MonoIn)

Single Stereo

Dual Stereo (MonoIn)

Dual Stereo

Cascade Stereo

Dual Mono

Quad Mono

Cascade Mono

Dual Mono + Single Stereo

Cascade Mono to Stereo

Single Two In Four Out

Single Four In Four Out

Single Two In Five Out

Single Five In Five Out

Single Six In Six Out

For more detailed descriptions of each configuration, see page 16.

Midi Control

The MIDI Control sub-menu lets you adjust the following MIDI-related

options:

MIDI

Turns MIDI processing on or off.

Device ID

Select the connected MIDI device’s ID here. Choose from 0-126.
