User's Guide ADI-6432R BNC © RME
5. Accessories
RME offers several optional components for the ADI-6432, for example MADI Optical Cable:
ONK0100 MADI Optical Network Cable, 1 m (3.3 ft)
ONKD0300 MADI Optical Network Cable, 3 m (9.9 ft)
ONKD0600 MADI Optical Network Cable, 6 m (19.8 ft)
ONKD1000 MADI Optical Network Cable, 10 m (32.8 ft)
ONKD2000 MADI Optical Network Cable, 20 m (65.6 ft)
ONKD5000 MADI Optical Network Cable, 50 m (164 ft)
6. Warranty
Each individual ADI-6432R BNC undergoes comprehensive quality control and a complete test
at IMM before shipping. The usage of high grade components should guarantee a long and
trouble-free operation of the unit.
If you suspect that your product is faulty, please contact your local retailer.
Audio AG grants a limited manufacturer warranty of 6 months from the day of invoice showing
the date of sale. The length of the warranty period is different per country. Please contact your
local distributor for extended warranty information and service. Note that each country may
have regional specific warranty implications.
In any case warranty does not cover damage caused by improper installation or maltreatment -
replacement or repair in such cases can only be carried out at the owner's expense.
No warranty service is provided when the product is not returned to the local distributor in the
region where the product had been originally shipped.
Audio AG does not accept claims for damages of any kind, especially consequential damage.
Liability is limited to the value of the ADI-6432R BNC. The general terms of business drawn up
by Audio AG apply at all times.
7. Appendix
RME news and further information can be found on our website:
http://www.rme-audio.com
Distributor: Audio AG, Am Pfanderling 60, D-85778 Haimhausen, Tel.: (49) 08133 / 91810
Manufacturer:
IMM Elektronik GmbH, Leipziger Strasse 32, D-09648 Mittweida
Trademarks
All trademarks and registered trademarks belong to their respective owners. RME, Hammerfall
and DIGICheck are registered trademarks of RME Intelligent Audio Solutions. ADI-6432,
SteadyClock, SyncAlign, SyncCheck and Intelligent Clock Control (ICC) are trademarks of RME
Intelligent Audio Solutions. S/MUX is copyright Sonorus.
Copyright © Matthias Carstens, 04/2011. Version 1.1
