15.2 Lock, SyncCheck and SyncAlign

Digital signals consist of a carrier and the data. If a digital signal is applied to an input, the re-

ceiver has to synchronize to the carrier clock in order to read the data correctly. To achieve this,

the receiver uses a PLL (Phase Locked Loop). As soon as the receiver meets the exact fre-

quency of the incoming signal, it is locked. This Lock state remains even with small changes of

the frequency, because the PLL tracks the receiver's frequency.

If an AES signal is applied to the ADI-6432, the corresponding SYNC LED starts flashing. The

unit indicates LOCK, i. e. a valid input signal (in case the signal is also in sync, the LED is con-

stantly lit, see below).

Unfortunately, LOCK does not necessarily mean that the received signal is correct with respect

to the clock which processes the read out of the embedded data. Example [1]: The ADI-6432 is

set to 44.1 kHz internal clock, and a CD-Player is connected to input AES1. The corresponding

LED will start flashing immediately, but the CD-Player's sample rate is generated internally, and

thus slightly higher or lower than the ADI-6432's internal sample rate. Result: When reading out

the data, there will frequently be read errors that cause clicks and drop outs.

Also when using multiple inputs, a simple LOCK is not sufficient. The above described problem

can be solved elegantly by setting the ADI-6432 from internal clock to AES (its internal clock will

then be the clock delivered by the CD-Player). But in case a DAT recorder is connected as a

second source, there will again be a slight difference in the sample rate, and therefore clicks

and drop outs [2].

In order to display those problems optically at the device, the ADI-6432 includes SyncCheck. It

checks all clocks used for synchronicity. If they are not synchronous to each other (i. e. abso-

lutely identical), the SYNC LED of the asynchronous input flashes. In example 1 it would have

been obvious that the SYNC AES1 LED kept on flashing after connecting the CD-Player. In

example 2, SYNC AES1 would be constantly lit, but the SYNC LED of the input used by the

DAT would be flashing.

In practice, SyncCheck allows for a quick overview of the correct configuration of all digital de-

vices. This way one of the most difficult and error-prone topics of the digital studio world finally

becomes easy to handle.

A special problem occurs with devices offering several AES or SPDIF inputs. While with MADI

all 64 channels share the same clock base, with AES there are several completely independent

receivers with their own PLLs and data buffers. Therefore a random error of ± 1 sample differ-

ence between the stereo pairs can occur. The ADI-6432's exclusive SyncAlign technology

avoids this effect and guarantees sample synchronicity among all four stereo channels.
