14.6 Firmware

The ADI-6432's main part has been realized using programmable logic. By re-programming of a

little component called Flash-PROM, both function and behaviour of the unit can be changed at

any time.

At the time of writing this manual, the unit is shipped with firmware 1.5. The firmware version is

displayed after power on for about one second by the SYNC and AUDIO LEDs of the AES

INPUT STATE section.

14.7 Connector Pinout RS232

The 9-pin D-Sub Connector is wired according to industry standard:

Signal In (Rx) Out (Tx) GND NC

D-sub 2 3 5 9

Internally connected are pins 1 with 6 and 4, and pin 7 with 8.

14.8 MADI User Bit Chart

• RS-232: channels 1 to 9

• ADC: channel 19

• MIDI: channel 56 (48k) / 28 (96k)
